BRT8060 Explosion-Proof Fuse Module

Technical Data

1.Explosion-proof Type

• Standards Implemented: CENELEC, IEC, NEC
• Applicable Hazardous Areas: Zone 1, Zone 2 (hazardous areas for explosive gas), Zone 21, Zone 22 (hazardous areas for combustible dust)
• Ex Marking: Gas protection: Ex eb mb IIC Gb

2.Product Parameters

• Product Type: BRT8060 Explosion-proof Fuse Module
• Certification: Explosion-proof marking Ex eb mb IIC Gb
• Material: Housing injection-molded from custom-made engineering plastics
• Exposed Fasteners: No relevant information indicated on datasheet
• Electrical Specifications-Rated Voltage: 250V
• Electrical Specifications-Rated Current: 1A,2A,4A,6A,8A,10A,20A,50A,100A
• Protection-Ingress Protection Rating: IP20
• Ambient Temperature: Ambient: -40℃ ~ +60℃; Operating: -40℃ ~ +75℃
• Connection & Input-Cable Cross-section: No relevant parameters on datasheet

3.Product Classification & Origin

HS Code: 8536100000
Country of Origin: China

4.Applicable Industries

• Applicable for: Suitable for petroleum, chemical, coal‑chemical, pharmaceutical, oil‑gas storage and other high‑risk industries with explosive gas and combustible dust.
• Practicality: It supports base‑plate and DIN‑rail mounting. DIN‑rail type fits standard TS15/TS35 rail. Compact structure enables convenient installation, inspection and fuse replacement.
• Safety performance: With explosion‑proof marking Ex eb mb IIC Gb, it meets the application requirements of Zone 1, Zone 2, Zone 21 and Zone 22 hazardous locations. It provides short‑circuit and overload protection for circuits. It shall be equipped with increased‑safety enclosure to guarantee electrical safety under hazardous working conditions.

5.Credibility

MMALATEX explosion-proof products comply with strict international standards and hold complete ATEX, IECEX and EAC certifications to ensure compliant operation in global markets. This series of explosion-proof products is engineered for extreme working conditions with IP65/IP66/IP67 protection ratings, delivering excellent resistance to water, dust and corrosion. We provide customers with in-depth supporting services, including comprehensive technical support, complete warranty services and worldwide logistics support. Wherever your project is located, MMALATEX ensures smooth project delivery and provides safe and reliable solutions for hazardous areas.

6.FAQs

Q1: What is the explosion-proof marking of BRT8060 explosion-proof fuse module?

A1: Its explosion-proof marking is Ex eb mb IIC Gb.

Q2: Which hazardous zones is BRT8060 suitable for?

A2: It is applicable to Zone 1, Zone 2, Zone 21 and Zone 22.

Q3: Can BRT8060 explosion-proof fuse module work alone in explosive gas atmosphere?

A3: No. It must be used with increased-safety enclosure and cannot be used separately in explosive gas environment.
